0.96" OLED 128x64 I2C Display SSD1306

http://www.abdullah-electronics.com/web/image/product.template/10/image_1920?unique=25ea2c9
(0 review)
The 0.96" OLED 128×64 Display Module is a compact and efficient screen designed for embedded systems and microcontroller projects. Powered by the SSD1306 driver, it communicates over the I2C interface using just two data lines. Despite its small size, it delivers sharp contrast, making it ideal for displaying text, graphics, and real-time data.

4,500 IQD 4500.0 IQD 4,500 IQD

4,500 IQD

Not Available For Sale

  • Color

This combination does not exist.

Contact Us

Terms and Conditions
Shipping: 2-3 Business Days

Share

Features Applications

Features

  • Clear 128×64 pixel resolution
  • Uses SSD1306 display driver
  • Communicates via I2C (4-pin)
  • Low power consumption
  • Compatible with Arduino, ESP32, Raspberry Pi, STM32, and others
  • Available in White, Blue, and Yellow/Blue split-color options

Applications

  • Data display for IoT sensors and devices
  • Compact user interfaces
  • Clocks, meters, and wearable gadgets
  • System monitors for battery or environment
  • DIY electronics and portable tools
General Environmental Physical

General

  • Display Size: 0.96 inch (diagonal)
  • Resolution: 128 × 64 pixels
  • Driver IC: SSD1306
  • Interface: I2C (VCC, GND, SDA, SCL)
  • Operating Voltage: 3.3V to 5V DC
  • Color Options: White / Blue / Yellow-Blue
  • Viewing Angle: >160°

Environmental

  • Operating Temperature: -30°C to +70°C
  • Humidity: ≤85% RH (non-condensing)

Physical

  • Dimensions: Approx. 27mm × 27mm × 4mm
  • Mounting: Solder pads or header pins
  • Weight: ~3g
